Westermo MD-62 AC - Factory Settings

10 6070-2001
Switch settings MD-62
The MD-62 can, through switch settings, be set in to several modes. To set the switches,
open the plastic case by removing the top cover.
Status signal
Factory settings
S1 Enabled
ON
123456789
S1 Disabled
ON
123456789
S1
ON
123456789
S2
ON
12345
S2
ON
12345
Switch S1: 2–9 not used
Transmitted power
Low
S2
ON
12345
High
Switch S2: 1–4 not used
S1:1-9 S2:1-5
