Western Airconditioning Epsilon Echos+ 9 - Dimensional Drawings and Footprints

Epsilon Echos +
31
DIMENSIONAL DRAWING
Dimensional diagram Epsilon Echos+
9-15-1P
C413206 - A
"A"
CLEARENCES
G1 G2
G4 G3
FOOTPRINT
430
376
1350
926
30
370 269 230
151,5
O 10HOLES
155 616 155
17,539517,5
430
40
576
40
135135
300
300
600
900
VIEW FROM "A"
Pm
Es
481,5
Ep
Rp
Lh
Rp
Uin
Uout
Uin
A
B
B
HYDRAULIC CONNECTIONS
WITHOUT HYDRAULIC MODULE
HYDRAULIC MODULE ST1P
A
B
Cdh *
NOTE
ONLY ON HP VERSION (ø18 mm)
Cdh *
A
Uin Uout
A - B A - B
G 1" M G 1" M
MODEL WEIGHT(Kg) OPERATING WEIGHT(Kg) G1(Kg) G2(Kg) G3(Kg) G4(Kg)
EPSILON ECHOS PLUS 9 CH 153 154 38 17 29 70
EPSILON ECHOS PLUS 15 CH 156 157 40 17 29 71
EPSILON ECHOS PLUS 9 CH_1P 163 166 46 18 28 74
EPSILON ECHOS PLUS 15 CH_1P 168 171 48 18 28 77
EPSILON ECHOS PLUS 9 HP 166 167 42 19 32 74
EPSILON ECHOS PLUS 15 HP 168 169 43 19 32 75
EPSILON ECHOS PLUS 9 HP_1P 177 179 50 20 31 79
EPSILON ECHOS PLUS 15 HP_1P 181 184 51 21 31 81
Denomination - Dimensional Drawing Drawing Rev.
DraftsmanDate
Scale
Checked by
di
Sheet
N.
of
Replace draw. Replaced by draw.
Weight [kg]
DIM.DRAWING EPSILON ECHOS PLUS 9-15-1P
C413206/
A
BARBETTA
1
/
/
1
TURRI16/11/121:20
/
Code
MTE 56 rev. 04 date: 07/04/11
Reserved property, reproduction prohibited accordin to existent
laws.Copyright.
