Western Airconditioning Epsilon Echos+ 9 - Page 39

Epsilon Echos +
39
Dimensional diagram Epsilon Echos+
LE-LE/HP 26-30
C413214 - A
"A"
CLEARENCES
G1
G2
G4
G3
FOOTPRINT
618
506
1585
1306
1067 466 52
O 10HOLES
1300
460 500
80
1140
80
300
Denomination - Dimensional Drawing Drawing Rev.
DraftsmanDate
Scale
Checked by
di
Sheet
N.
of
Replace draw. Replaced by draw.
Weight [kg]
DIM.DRAWING EPSILON ECHOS PLUS LE-LE/HP 26-30
C413214/
A
BARBETTA
1
/
/
1
TURRI16/11/121:25
/
Code
MTE 56 rev. 04 date: 07/04/11
Reserved property, reproduction prohibited accordin to existent
laws.Copyright.
R
VIEW FROM "A"
Pm
Es
Ep
Rp
Lh
Rp
Rc
Rc
Cdh *
NOTE
OPTIONAL (ø22 mm)
Cdh *
2020
300
600
900
37 500 81
282
MODEL WEIGHT( Kg) OPERA TING WEIGHT(Kg) G1(Kg) G2( Kg) G3(Kg) G4(Kg)
EPSILON ECHOS PLUS 26 LE 248 248 64 36 54 94
EPSILON ECHOS PLUS 30 LE 249 249 68 40 53 88
EPSILON ECHOS PLUS 26 LE/HP 265 265 68 39 58 100
EPSILON ECHOS PLUS 30 LE/HP 266 266 72 43 57 94
