Epsilon Echos +
38
Dimensional diagram Epsilon Echos+
LE-LE/HP 20
C413213 - A
"A"
CLEARENCES
G1
G2
G4 G3
FOOTPRINT
596
506
1385
1105
1064 270,5 50
192
O 10HOLES
1100
2046020
500
85
930
85
300
Denomination - Dimensional Drawing Drawing Rev.
DraftsmanDate
Scale
Checked by
di
Sheet
N.
of
Replace draw. Replaced by draw.
Weight [kg]
DIM.DRAWING EPSILON ECHOS PLUS LE-LE/HP 20
C413213/
A
BARBETTA
1
/
/
1
TURRI16/11/121:25
/
Code
MTE 56 rev. 04 date: 07/04/11
Reserved property, reproduction prohibited accordin to existent
laws.Copyright.
Rev. Da
VIEW FROM "A"
Pm
Es
Ep
Rp
Lh
Rp
Cdh *
300
600
900
NOTE
OPTIONAL (ø22 mm)
Cdh *
43
500 53
MODEL WEIGHT(Kg) OPERATING WEIGHT(Kg) G1(Kg) G2( Kg) G3(Kg) G4(Kg)
EPSILON ECHOS PLUS 20 LE 210 210 46 30 53 81
EPSILON ECHOS PLUS 20 LE/HP 223 223 49 32 56 86
