Epsilon Echos +
37
Dimensional diagram Epsilon Echos+
LE-LE/HP 9-15
C413212 - A
"A"
CLEARENCES
G1 G2
G4 G3
FOOTPRINT
430
376
1350
926
30
851 269 230
151,5
O 10HOLES
155 616 155
17,539517,5
430
40
576
40
135135
300
300
600
900
Denomination - Dimensional Drawing Drawing Rev.
DraftsmanDate
Scale
Checked by
di
Sheet
N.
of
Replace draw. Replaced by draw.
Weight [kg]
DIM.DRAWING EPSILON ECHOS PLUS LE-LE/HP 9-15
C413212/
A
BARBETTA
1
/
/
1
TURRI16/11/121:20
/
Code
MTE 56 rev. 04 date: 07/04/11
Reserved property, reproduction prohibited accordin to existent
laws.Copyright.
VIEW FROM "A"
Pm
Es
Ep
Rp
Lh
Rp
Rc
Rc
Cdh *
NOTE
ONLY ON HP VERSION (ø18 mm)
Cdh *
34
464
MODEL WEIGHT(Kg) OPERATING WEIGHT(Kg) G1(Kg) G2(Kg) G3(Kg) G4(Kg)
EPSILON ECHOS PLUS 9 LE 144 144 32 15 32 65
EPSILON ECHOS PLUS 15 LE 148 148 33 16 32 67
EPSILON ECHOS PLUS 9 LE/HP 157 157 35 18 35 68
EPSILON ECHOS PLUS 15 LE/HP 159 159 36 18 35 70
