Lit. No. 72451, Rev. 03 16 October 15, 2019
OPERATING YOUR SNOWPLOW
Joystick Control Functions
Raise, Lower, Float, Angle
Moving the control lever straight up and down or from
side to side on the control body will result in the blade
movements described in the following table.
Function Description of Operation
RAISE
Move the control lever toward the top of the
control body to raise the blade and cancel
the FLOAT mode. Function times out after
4.0 seconds.
LOWER
Move the control lever toward the bottom of
the control body to lower the blade. Release
the lever to stop blade at the desired height.
FLOAT
†
Move the control lever to the LOWER position
and hold 3/4 second to activate this mode.
The FLOAT light in the upper left corner of
the control face will illuminate. The blade will
lower to the ground surface and follow the
contour of the surface as it dips or rises. This
function does not time out, but the control will
shut down after 20 minutes of nonuse.
Move the lever to the RAISE position
momentarily to cancel FLOAT. Angling left
or right will not interrupt (pause) the FLOAT
function.
L
(Angle
Left)
Move the control lever straight to the left to
angle the blade left. Function times out after
3.0 seconds.
R
(Angle
Right)
Move the control lever straight to the right to
angle the blade right. Function times out after
3.0 seconds.
†
FLOAT mode activates immediately when the one-touch FLOAT
feature is enabled. See "One-Touch FLOAT" later in this section
for more information.
NOTE: If a control function times out before the
desired blade movement is complete, release the
lever to the center position, then move it back into
the desired function.
