7 SPECIFICATIONS

7.1 MECHANICAL

WEIGHT LBS. (Kg)

EMPTY FULL

965 LBS (437) 1901 LBS (862)

1118 LBS (508) 2994 LBS (1358)

1825 LBS (828) 5574 LBS (2528)

2153 LBS (972) 7765 LBS (3522)

3567 LBS (1618) 12235 LBS (5550)

*ALL WEIGHTS ARE APPROXIMATE

SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE

MODEL CAPACITY

IMP. US LITER

GAL. GAL.

05TCG 110 132 500

10TCG 220 264 1000

20TCG 440 528 2000

30TCG 660 792 3000

50TCG 1040 1247 4725

DIMENSIONS

IMPERIAL / METRIC (MM)

LENGTH WIDTH HEIGHT

45 1/4" (1155) 45 1/4" (1155) 33" (838)

45 1/4" (1155) 45 1/4" (1155) 52" (1320)

86 1/4" (2190) 45 1/4" (1155) 52" (1320)

90 1/2" (2300) 59 1/8" (1500) 52" (1320)

90 1/2" (2300) 90 1/2" (2300) 52" (1320)
