Lit. No. 49513, Rev. 04 83 June 15, 2022
HYDRAULIC SYSTEM
Fluid Level
NOTE: On MVP PLUS™ and WIDE-OUT™
blades, add uid only when all rams are
retracted.
NOTE: Remove the ll plug slowly to relieve
any pressure in the reservoir.
1. With the UltraMount
®
system attached to the
vehicle, activate the control.
MAINTENANCE
2. For straight blades any angle will do, but for
MVP PLUS and WIDE‑OUT blades, move
the blade wings to the fully retracted (vee)
position.
3. Activate the control FLOAT function and
manually collapse the lift ram all the way.
CAUTION
Do not mix dierent kinds of hydraulic
uid. Some uids are not compatible and
may cause performance problems and
product damage.
HTS™ Blades
Breather/Fill Plug
Drain
Plug
To Next Page
