3. Assembly & Adjustments
3.1 Assembling and adjusting the handlebar
• Place the handlebar onto the handlebar stem, place on the cover, and fi x with the
four screws provided. The tighten torque should not be less than 18 Nm.
Handlebar
stem cover
Hexagon socket screws
Handlebar stem
• To align the handlebars, face your bike and hold the front wheel between your
legs. Turn the handlebars so that they are perpendicular to the front wheel.
• Tighten the screw that fi xes the handlebar attachment to the frame. The
tightening torque should be no less than 18 Nm.
Handlebar
stem screw
