Assembly Instructions
7
Slide upper spray gun holder (A) tab into slot on left side
of power washer unit (D).
From below, slide lower sprayer gun holder (B) tabs into
slots on bottom left side of power washer unit (D).
Hold back the collar at one end of the end of the hose
(H). Push firmly to connect hose fitting to the water outlet
tube on the front of the power washer unit (D). Twist the
collar clockwise to secure. Confirm hose is locked into
the water outlet by slightly pulling on the hose.
Note: DO NOT use pliers or locking pliers to tighten.
3
A
D
D
B
4
5
H
D
