18. Setting Payment Systems
1 . S E T T I N G U P COI N ME CH
The coin mechanism must be connected and disconnected
with the machine turned off.
The connectors required to connect the coin mechanism
are located next to the main board.
Slacken the pre-fitted
screws as shown.
The coin mech is
located next to the
main board.
Place the coin mech
into place - secure by
tightening the screws.
To fit the coin mech:
1.
2.
3.
