DonotuseREVrotationtopullthecableoutofthedrain.Alwaysrun
themachinewiththeRotationSwitchsettoFORposition,whetheryouarefeedingthe
cableintothelineorpullingitout.
12. Whenthecuttingtoolisnearthedrainopening,takeyour
footofftheFootSwitchtostop
drumrotation.Neverretractthecuttingtoolfromdrainwhilecableisrotating.Thecable
couldwhipandcauseseriousinjury.

CableClampingwithCableLockScrew

ThismachineisdesignedwithaCableLockScrew.When
strongresistanceismet,putthe
CableFeederLevelatthe
middleposition.TightentheCableLockScrewwhenletting
thecutterchewthestoppage.
DonotusetheCableFeederwhentheCable
LockScrewistightened.UsingtheCableFeederwiththe
CableLockScrewbeingtightenedwillcausedamagetothe
machine,whichmayresultinpersonalinjury.Soplease
remembertoreleasethescrewwhenevertheCableFeederis used.

Special
OperationsWhenCableGetsStuckInLine

Themotorcanbereversedtofreecableifthecablegetsstuckinthelinebyusingthefollowing
procedure:
1. TurntheRotationSwitchtoREVposition,andpushtheCableFeederLevertoMiddle
position
2. DepresstheFootSwitch
afewsecondsandpullthecablebackwhilethedrumisrotatingin
Reversedirection.
3. Whenthecablehasbeenfreed,settheRotationSwitch toFORposition.
DonotrunmotorinReversedirectionformorethanafewsecondsatatimesince
thiscouldcausecabletanglinginthedrumorkinking.

SpecialOperationsWhenCableTanglesinDrum

Tountanglecable,rotatedrumintheREVdirectionwithhand.Thiswillusuallygetthe
cabletolie
inthedrumproperly.
:YouMUSTturntheRotationSwitchtoOFFandtakeyourfeetawayfromthe
FootSwitch.Failingtodothismaycauseaccidentalstartingandinjury.

Ifcablebecomesseverelytangled,whichshouldnotoccurwhenusedproperly,youwillneedto
replaceitwithanewcable.

OperationwithTorque‐AdjustingThumbWheel
Thismachineisequippedwithatorque‐adjustingThumb
Wheelforlimitingthetorqueappliedtobeltandprevent
cabledamagewithregularoperation.Whenthetorque
transmittedfromthecablereachesthelimitsetbythe
ThumbWheel,thebeltwillslipon
thepulley.Thiswill
preventthecablefromtwistingorkinking.
Thetorquehasbeenpre‐adjustedproperlyinmanufacture,
andinmostcaseswillneverneedtobeadjusted.
