Westward Operating Instructions and Parts Manual
22XP38, 22XP39
Drain Cleaning Machine
Specifications
Item 22XP39 22XP38
Motor 120V~/60Hz/5.3A(Running), 1/3HP/ 1716RPM
PowerCordLength
6’ long with GFCI
DrumDimension
Φ
13”×6.3”
DrumCapacity
1/2”Dia.×75’Long
3/8”Dia.×100’Lo ng
CableType 3/8”Dia.×75’Long 1/2”Dia.×75’Long
DrainPipeCapacity 11/2”to3”(38mmto76mm) 3”to4”(76mmto101mm)
Dimensions 22.0” ×14.6”×23.6”(55.9 cm×37.1cm×59.9cm)
Weight
MachineOnly:57.7lbs (26.2kg)
WithCable:73.6lbs(33.4kg)
MachineOnly:57.7lbs (26.2kg)
WithCable:93.2lbs(42.3kg)


WiringDiagram


GeneralSafetyRules
SafetySymbols
Pleaserefertothefollowingsymbolsforthelevelofdangers.Operatorsshouldbeawareofthe
degreeofdangerswhenmachineismisused.
Warnsaboutha zard stha twillcauseseriouspersonalinjury,death,ormajor
propertydamageifignored.
Warnsaboutha zard stha tcouldcauseseverepersonalinjury, death,ormajor
propertydamageifignored.
Warnsabouthazardsthatmaycauseminorpersonalinjuryorproperty
damageifignored.
