SYSTEM OVERVIEW
To illustrate how the above-mentioned items are connected, a technical drawing of the general
principles of the Wexer Virtual system is included below:
AV GUIDE
To help you select the right hardware, we have outlined a few details and suggestions below:
TV Projector Projector screen
TV wall (with a minimum of
4 screens)
3m (horizontal width) 1.78m
(vertical width) or 135'' (bigger
the better)
Minimum screen resolution 1280×720 1280×720 NA
Minimum ANSI lumens NA 3000 lumen NA
The display ratio must be 16:09 16:09 16:09
The source inputs must include
1 x HDMI (ONLY for Basic
Player) or 1 x VGA + 1
Audio output (works for
both players)
Mounting requires Wall Ceiling Wall
Screen for multipurpose studio NA NA Motorized screen
Screen for group x or c ycling studio NA NA Fixed screen
I have no ambient light NA 3000 lumen Low Gain
I have natural ambient light NA 5000-6500 lumen High Gain
