WFCO WF-8900-REP Series User Manual

OPERATIONAL FEATURES
WF-8900-REP Performance Features
e WF-8900-REP Converter Replacement Kit provides all of WFCO’s performance
standards:
• Quiet Operation
• Filtered Power
• Overload Protection
• Short Circuit Protection
• FCC Class B Approval
INSTALLATION INSTRUCTIONS
Installing the WF-8900-REP Kit
Tools Needed for Assembly:
• Safety Glasses
• Large and Small Straight Blade Screwdriver
• #2 Phillips Screwdriver
• #2 Square Drive Screwdriver
• Pliers
• 1/4” Nutdriver
• 5/16” Nutdriver
Step-By-Step Installation:
Before beginning installation, Make sure no AC power is coming into the RV from
either the Shore Power cord or an on-board generator. Remove and set aside the
Reverse Polarity Fuses located on the fuse board to disconnect the converter section
from the rest of the RV’s DC power.
In order to install the WF-8900-REP Kit, you must rst remove the existing
converter section in your power center. is kit can be used on several dierent products.
Your power center may dier slightly in the removal process.
Removing the original converter section:
Removal of the original power center is divided into 3 segments:
• Removing the AC (110 volt) side of the converter
• Removing the DC (12 volt) side of the converter
• Removing the converter MBA (Main Board Assembly)
4
