E SERIES INSTALLATION MANUAL

SPEED 0.00 0.05 0.10 0.15 0.20 0.25 0.30 0.35 0.40 0.45 0.50 0.60 0.70 0.80 0.90 1.00

E024

Max 1020 CFM High* 1020 1003 984 961 940 908 882 845 810 772 717 653 - - - -

Rated 700 Med 801 795 784 776 761 742 714 692 672 628 580 - - - - -

Min 580 CFM Low 713 705 691 694 674 665 645 616 594 - - - - - - -

E030

Max 1275 CFM High* 1275 1252 1230 1210 1179 1152 1108 1079 1030 991 955 849 687 - - -

Rated 900 Med 1052 1042 1034 1027 1001 993 959 940 908 868 836 744 - - - -

Min 720 CFM Low 847 845 844 846 830 829 805 793 768 739 720 - - - - -

E035

Max 1420 CFM High* 1420 1391 1357 1329 1294 1254 1212 1167 1119 1067 1016 892 - - - -

Rated 1100

Med 1214 1199 1185 1152 1127 1096 1056 1031 1002 956 908 - - - - -

Min 890 CFM Low 1077 1070 1058 1046 1034 1006 974 953 925 890 - - - - - -

E040

Max 1610 CFM High* 1610 1588 1568 1536 1498 1469 1427 1388 1360 1293 1229 1128 - - - -

Rated 1300 Med 1397 1374 1360 1344 1302 1298 1269 1237 1189 1162 1105 - - - - -

Min1040 CFM Low 1100 1092 1081 1066 1055 1040 - - - - - - - - - -

E047

Max 1800 CFM High* - 1800 1760 1725 1690 1632 1584 1523 1474 1399 1308 1194 - - - -

Rated 1500 Med 1571 1547 1518 1486 1456 1414 1388 1331 1281 1236 1168 1080 - - - -

Min 1080 CFM Low 1183 1175 1162 1149 1136 1111 1085 - - - - - - - - -

E058

Max 2160 CFM High* - - - - - - 2160 2115 2057 2016 1963 1860 1722 - - -

Rated 2000 Med - - - 2141 2105 2072 2034 1994 1947 1907 1861 1774 1650 - - -

Min 1550 CFM Low 2071 2049 2026 2000 1970 1941 1908 1872 1834 1792 1749 1655 1550 - - -

E066

Max 2300 CFM High* - - - - - 2300 2237 2199 2135 2102 2037 1938 1789 1725 - -

Rated 2200 Med 2282 2249 2224 2198 2157 2134 2091 2056 1995 1964 1915 1817 1676 - - -

Min 1630 CFM Low 2059 2030 2008 1983 1942 1924 1877 1853 1812 1770 1730 1630 - - - -

Notes: All units tested with a wet coil and clean 1-inch ﬁlter. E030 265 volt units are shipped on medium speed.

* Indicates factory settings

Fan Performance Data

PSC
