Fig. 28 Connect 12V connector
Fig. 29 Connect 12V to interface plate
Fig. 30 Mains electrical connection
Fig. 31 Mains connection
Fig. 32 Completed installation
Fig. 33 Completed installation under vehicle
Fig. 34 Control panel
Fig. 35 Flue Type - for vehicle in motion
Fig. 36 Flue Type - for standard installation
The Whale® Space Heater Mk II is a gas and electric blown air space heater. Nominal heat output is 2kW on gas
and 2kW on mains electric. When on electric mode, heat output is adjustable to low, medium and high settings with
an automatically adjusting fan speed which minimises noise and current draw. The compact design provides versatili-
ty in installation locations and needs minimal maintenance. The vehicle internal temperature is set by a room con-
troller which can be manually adjusted to a wide range of temperature settings or to warm weather ventilation. Key
enhancements to the Mk II design are improved insulation, improved service access and lighter more compact
design.
Read the following carefully before installation
Model: SH2202 (inside vehicle) Maximum dimensions: Height: 230mm, Width: 157mm, Length: 634mm
SH2212B (under-floor) Maximum dimensions: Height: 121mm, Width: 290mm, Length: 714mm
Countries of Destination: AT, BE, BG, CH, CY, CZ, DE, DK, EE, ES, FI, FR, GB, GR, HU, HR, IE, IS, IT, LT, LU, LV,
MT, NL, NO, PT, SE, SI, SK, TR
Weight: Inside Vehicle Installation 7.7kg
Under-floor Installation 7.7kg
Gas: Butane 28-30mbar - CAT I
3+
(28-30/37), Butane/Propane 30mbar - CAT I
3B/P
(30)
Propane 37mbar - CAT I
3p
(37)
Gas Consumption (M) 150g/h
Classification of Heater: Type: C
53
(Fanned) Normal Installation
C
13
Vehicle In Motion Installation
Nominal Heat Input: Gas 2.0kW
Nominal Heat Input Electric 2.0kW.
Mains Electric:
Nominal voltage: 230V a.c. 50Hz
Power options: 500/1000/2000W
Maximum current a.c.: 9 Amps
Battery Supply
Nominal voltage: 12V d.c.
Operating range: 10.0V d.c. min. to 15V d.c. max.
Maximum current d.c. gas operation: 1.7 Amps (0.01Amps on standby)
Maximum current d.c. electric operation: 2.2 Amps (0.01Amps on standby)
Dry Storage Temperature: -20°C to 70°C
Hot Air Duct Diameter: 60mm ID
Flue Diameter: 22mm ID
2. SPECIFICATION
1. PRINCIPLES OF OPERATION
2
To Next Page
