Whalen MLCRD - Parts Required

Please call for replacement parts or assistance: 1-866-942-5362
Whalen Furniture Mfg. Inc
Factory No. 5-1571
Page # 10
Assembly Instructions
12. Finish your assembly by inserting both the keyboard pullout and drawer into place.
13. When you open the Keyboard Pull-out you can flip down the keyboard front by pushing down
the Drop Down Latches on the keyboard front hardware on both ends, as shown in detail #5.
Parts Required Tools Required
Pre-attached Drop Down Latch No Tool Required
