Please call for replacement parts or assistance: 1-866-942-5362
Whalen Furniture Mfg. Inc
Factory No. 5-1571
Page # 4
Parts & Hardware List
Please read completely through the instructions and verify that all parts listed are
present before beginning assembly.
J- Return Back Panel (1) K- Curved Middle Panel (1)
L- Adjustable Shelf (1) M- Pencil Tray (2)
(Pre-attach)
(1)- 1 1/4'’ Bolt (25+1 extra) (2)- 3’’ Bolt (2+1 extra) (3)- Flat Washer (27+1 extra)
(4)- Shelf Pin w/Hole (4) (5)- 5/8” Screw (18+1 extra) (6)- Grommet (3)
(Pre-attach)
(7)- 1/2” Wood Screw (4) (8)- Figure“8” (pre-attach) Touch Up Pen (1)
(Pre-attach)
Tools Required: Phillips Screwdriver
