Model # PRO-9
Please call for replacement parts or assistance: 1-866-942-5362
Whalen Furniture Mfg. Inc. Page 6 Factory No. 33- 10944
Assembly Instructions
2. Pick up Back Panel (C) and fit it between the front of Left and Right Side Frames (A & B).
Insert and screw four #3 x 9 mm Screws (8) through the corner brackets to secure the Back
Panel in place. Tighten the screws with a Phillips Screwdriver. See detail #2.
Required hardware in this step
Description (8) #3 x 9mm Screw
Sketch
Qty. (4 pcs)
Tools required: Phillips Screwdriver
To Next Page
