3.ASSEMBLYPARTLIST
3
R/N P/N PART NAME DESCRIPTION QUA
1 088-1245000000 MAIN P.C.B 1
2 088-1245002200 ECHO P.C.B 1
3 088-1245000300 AMP P.C.B 1
4 088-1245003800 IMPROT P.C.B 1
5 022-1076902014 TRANSFORMER 1
6 041-2013000000 SWITCH R130-22C-11P 1
7 215-1247000011 KNOB ASHE 10
8 215-1247000022 KNOB REN 7
9 215-1247000033 KNOB ASHE 6
10 309-1245000001 MAIN FRAME 1
11 307-3000602401 CUPREOUS POLE 6
12 344-1245000001 PM500 CABINET 1
13 226-3800601111 RUBBER FOOT 4
14 524-3022080811A SCREWS SK(+)3*8MC H BZn 6
15 524-3003080811A SCREWS SK(+)3*8DA H BZn 10
16 527-3022180811A SCREWS SP(+)3*18MC H BZn 4
17 537-4001120801A SCREWS MP(+)4*12MC H BZn 4
18 541-4001240801A SCREWS MO(+)4*24MF OB 2
19 541-4001300801A SCREWS MO(+)4*30 MF OB 8
20 553-4001208061A SCREWS WT(+)4*20 DA HOB 4
21 553-4002168061A SCREWS WT(+)4*16DA HOB 32
