Installation instructions
S06U - 1
Power line - 1
Relay - 1
Microphone - 1
SOS line - 1
User manual - 1
1) Wiring instructions
1. Accessories list
2. Installation instructions
2.1 SIM card installation
Confirm whether the accessories are complete before
using , including:
Open the face shell according to the instructions in
figure 1 and load the SIM card. The device USES the
SIM card of standard specification.
The device has three sets of interfaces, interface 1
for microphone connection, interface 2 for power
supply connection, and ACC detection and relay.
Interface 3 is used to connect the SOS keys. Interface
2 is a 4-core wire, which are relay wire (yellow), power
positive pole (red), power negative pole (black), and
ACC detection wire (green).
