11
2.5 Seat Installation (Figure 7)
Seat Installation and Adjust:
a. Insert the Seat Adapter into the Seat-
Bushing.
(1) Verify that the Seat-Bushing
slot is in forward direction.
(2) Install bolt and washer and
tighten the bolts very well,
using the attached wrench.
(3) Install and tighten the
securing nut very well, using
the attached wrench.
(4) Install the Seat into the Seat-
Bushing while the Seat is
45 degree to the side of the
frame.
(5) Press the Seat Turning
Lever to place the Seat
forward position.
b. Adjusting the height of the Seat.
Remove nut, bolt and washer. Change
the Seat Adapter height, install, bolt
and washer and tighten strongly
tightened and tighten the securing nut
very well.
c. Install Seat Upholstery.
