47
CHAPTER 10 - SPECIFICATIONS *
DIMENSIONS: Metric (cm) U.S. (inches)
Width 62 24.4
Length with straight handlebars 115 45.3
Height of seat from floor 55-60 21.5-23.6
Ground clearance 7.5 3.0
WEIGHTS : Metric (kg) U.S. (lb.)
Tiller 10.3 22.6
Frame - complete 36.5 80.3
Frame (without: wheels,
batteries, seat, basket) 10.6 23.3
Batteries (each) 6.8 15.0
Wheel (each) 0.9 2.0
Seat 9.9 21.7
OPERATIONAL CHARACTERISTICS: Metric U.S.
Speed (Speed Selector switch)
Forward HIGH up to 7.5 km/h 4.7 mph
Forward LOW up to 4.5 km/h 2.8 mph
Reverse up to 4.5 km/h 2.8 mph
Maximum allowed load 110 kg 240 lbs.
Maximum rear basket load 10 kg 22 lbs.
Maximum traveling distance with fully
charged batteries (user weight 75 kg,
level surface, high speed)
20 km 12.5 miles
Maximum downhill slope allowed 13 % 7.4 deg.
Maximum uphill climb (slope) allowed 13 % 7.4 deg.
Turning radius 70 cm 27.5 inch
Minimum safe turning radius 80 cm 31.5 inch
OPERATIONAL CHARACTERISTICS: Metric U.S.
