P82969 J
Sheet 2 of 2
INDUSTRY CANADA REGULATIONS: (Only applicable for use in Canada)
• NOTICE: The Industry Canada (IC) label identifies certified equipment. This certification means that the equipment meets
certain telecommunications network protective operational and safety requirements as prescribed in the appropriate Terminal
Equipment Technical requirements document(s). The Department does not guarantee the equipment will operate to the user's
satisfaction.
• Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local
telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer
should be aware that compliance with the above conditions may not prevent degradation of service in some situations.
• Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations
made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the
user to disconnect the equipment.
• Users should ensure for their own protection, that the electrical ground connections of the power utility, telephone lines and
internal metallic water pipe system, if present, are connected together. This precaution may be particularly
Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection
authority, or electrician, as appropriate.
• RINGER EQUILAVENCE NUMBER: The Ringer Equivalence Number
(REN) assigned to each terminal device provides an
indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination of an interface
may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all
the devices does not exceed 5.
SPECIFICATIONS:
Table 1: Sound Output (dBA) and Current (REN) at Maximum Volume
24VDC 24VAC 48VDC 90Vrms/20Hz
Horn 109dB/2.5mA 109dB/4.0mA 109dB/3.0mA 109dB/4.5mA/.5A REN
Bell 104dB/2.5mA 104dB/4.0mA 104dB/3.0mA 104dB/4.5mA/.5A REN
Vibrating Chime 94dB/2.5mA 94dB/4.0mA 94dB/3.0mA 94dB/4.5mA/.5A REN
Single Chime 94dB/2.5mA 94dB/4.0mA 94dB/3.0mA 94dB/4.5mA/.5A REN
No Sound 2.5mA 4.0mA 3.0mA 4.5mA/.5A REN
NOTES:
1. Input Voltage Range: 24VDC = 20-30VDC, 24VAC = 20-30VAC, 48VDC = 36-60VDC, 90Vrms =40-130Vrms, 20-30Hz
2. For 24VDC, 24VAC, and 48VDC inputs, add 10% more input current when operating the unit at maximum input voltage. For
90Vrms inputs, add 40% more input current when operating the unit at maximum input voltage
3. dBA is measured on-axis in a non-reflective (free field) test room using fast meter response.
Table 2: Sound Output Volume Adjusting Range
Horn 109-82dB
Bell 104-76dB
Vibrating Chime 94-68dB
Single Chime 94-68dB
Table 3: Tone Description
Horn Broadband Horn
Bell 1560Hz Modulated (0.07 Sec. ON/Repeat
Vibrating Chime 700Hz (1.0 Sec. Decay/Repeat)
Single Chime 700Hz (1.0 Sec. Decay)
Table 4: Duty and Ring Cycle
Cycle 90Vrms/20-30Hz 24VDC/AC, 48VDC
Duty Cycle 33% Max. 100% Max.
Min. Ring Cycle ON Time 0.8 Sec. 0.8 Sec.
Min. Ring Cycle OFF Time 1.6 Sec. 0.8 Sec.
Max. Ring Cycle ON Time 10 Sec. Continues
Strobe Flash Rate: Nominal 1 Flash Minimum/Ring Cycle
Strobe Output: 15cd on axis.
AC Current: 0.150 Amps Max.
