1. GENERAL SPECIFICATIONS
Maximum Capacity:
6,000 lbs. 2720 kg.
Maximum Lift Height:
39.5” 1000mm
Down Position Height:
5” 127mm
Shipping Weight:
950 lbs. 430 kg.
Lift Time 1. Electric Power Pack
30 seconds
2. Air Hydraulic Power Pack
Electric 115 V 1 H.P. Motor, 1 PH
Air Motor, 100 P.S.I
Unique Automatic Mechanical Safety Hydraulic Velocity Fuse
2. TOOLS REQUIRED
7/16” wrench
5/16” wrench
5/8” wrench
Side cutters
3. SHIPPING CONTENTS
The complete Mid-Rise Lift series is contained in two (2) packages. The main structure is
packaged onto a shipping skid. The main structure comes fully assembled with lifting
arms, main rollers and hydraulics. The remaining items come
in an accessory box.
Accessory Box Items:
1 Power Pack Tow Cart (with power pack and wheels)
1 “T” Handle
4 Rubber Lift Blocks
2 Truck Adapters (Optional)
