11
Disassembly Procedure of coreboard box:
1. Disconnect the Power cord from the Mains supply.
2. Remove the Mounting Screws and connectors.
IMPORTANT
# Be careful when using the Multimeter measuring probes, as they may damage the
Connector terminals.
Mounting screws
