20
SERVICE PART LIST:
NO.
PART NO. DESCRIPTION QTY
1 W10415631 OIL CHARGED COMPRESSOR ASSEMBLY ASD65 1 EA
2 W10533545 FC FOAMED DOOR REAL STEEL ELT GENX-2 1 EA
3 W10530157 GASKET SUB-ASSY FC GENX 1 EA
4 W10533940 305L RC FOAMED DOOR REAL STEEL GENX-2 1 EA
5 W10473472 PUSH IN GASKET (B) - RC 292L GENX 1 EA
6 9836040000 SCREW ANCHOR 10 EA
7 A201354000D PHILIPS HEAD SCREW M5.5X1.8 6 EA
8 A2253030000 SWITCH ROCKER ARM, NC- ESBEE W welded 1 EA
9 A2018890000 SCREW ANCHOR - plastic 4 EA
10 W10422954 RIVET AL POP - 4 MM 2 EA
11 W10478024 SCREW-TRILOBULAR M6X1.0 HEX HEAD 8 EA
12 W10468710 Sleeve for Suction Complement 1 EA
13 W10412104 CRISPER 21.4 L GENX 2 1 EA
14 A201354000D PHILIPS HEAD SCREW M5.5X1.8 4 EA
15 A2243500000 M 4.8 X 13 SELF TAPPING SCREW - ONYX 1 EA
16 A201356000B SCREW- Philips Head ,M4.8 x 16 4 EA
17 A201358000E PHILIPS HEAD SCREW, M4.0X0.7 2 EA
18 W10407116 ICE COLLECTOR L60 1 EA
19 W10511077 ICE TWISTER BRACKET WITH SUPPORT L60 1 EA
20 A211638380A COMPRESSOR SLEEVE-GNF 4 EA
21 A2221470000 BULB APPLIANCE, E14 1 EA
22 A2221820000 BULB HOLDER - DUO 1 EA
23 D111204100D HEX NYLOC NUT M6 4 EA
24 W10169462 FAN BLADE 90MM DIAMETER 1 EA
25 A2221170000 MI AC MOTOR FOR DUO 1 EA
26 W10412066 HANDLE FC BACK BREATH 1 EA
27 W10412070 HANDLE RC BACK BREATH 1 EA
28 W10412095 TRIVET FC GENX 2 2 EA
29 W10412097 HALF SHELF FC GENX 1 EA
30 W10412105 TRIVET RC- GENX 2 2 EA
31 W10412106 SHALLOW BIN GENX 2 EA
32 W10412110 LENS IN DIFFUSER 1 EA
33 W10543105 KNOB - Freezer Damper / Thermostat(HIPS) 1 EA
34 W10412129 COMPRESSOR MOUNTING PLATE ASSY GENX 1 EA
35 W10598320 Chiller GenX-Quick chill Graphics 1 EA
36 W10528523 HINGE BOTTOM ASSEMBLY, GENX 1 EA
37 W10418501 Screw Trilobular M6 X 1.0 Hex Head 3 EA
To Next Page
