CONTROLS & ELECTRONICS CONFIGURATION:
Top Mount: Deluxe models:
This refrigerator is managed by an Electronic System, mainly consisting of the components:
• Electronic Control Board (Hercules- Dlx (BEE))
• POT (Potentiometer) in case of Dlx (BEE) models only.
• Temperature Sensors {refrigerator, Defrost}
• Compressor ( With Run capacitor)
• Freezer Fan Motor (AC)
• Defrost Heater ( Integrated Al tube 200W)
• Door Open Sensing
These components are described as shown below.
– Electronic Control
The complete operation of this product is done by the Electronic Control, Functions of this models
are fully controlled by the Micro-controller IC which executes the functions according to the needs,
turning the components On or Off through received/managed signals, such as:
- Compressor On/Off
- Defrost Heater On/Off
- Temp setting in refrigerator Compartment, through received signals by the POT along with the
RC & FC Sensors Temp. Feedback.
- Door open sensing / Alarm
- Among many other functions controlled by its software.
