Whirlpool ACD052MM User Manual (English)

Questions and Answers:

J
Jerry WilsonAug 17, 2025
How to fix a Whirlpool Air Conditioner that won't turn on?
- B
  Barbara TownsendAug 17, 2025
  If your Whirlpool Air Conditioner isn't running, here are a few things to check: * No power: Verify that there is power at the receptacle and that the plug is making good contact. Also, inspect the fuses to ensure they are the correct size and time delay type. * Low voltage: Low voltage can prevent the unit from starting. * Failed component or incorrect wiring: Examine all wiring and connections, as well as the thermostat, selector switch, or control for any issues.
Y
yangcoryAug 19, 2025
What to do if my Whirlpool ACD052MM has no cooling but the compressor and fan are running?
- P
  petersoncarrieAug 19, 2025
  If your Whirlpool Air Conditioner's compressor and fan motor are running but there is no cooling, check the following: * Airflow restriction: Ensure there is proper airflow through both the condenser and evaporator. * Sealed system problem: Inspect the sealed system for any loss of refrigerant or restrictions.
J
jasonpalmerAug 22, 2025
What to do if the Whirlpool ACD052MM remote control does not operate the unit?
- A
  anthony87Aug 22, 2025
  If the remote control for your Whirlpool Air Conditioner isn't working, try these steps: * Check batteries: Ensure the unit operates manually at the control panel. If it does, replace the batteries in the remote. * Remote failure: If new batteries don't solve the issue, the remote may need to be replaced.
C
Cole WoodAug 25, 2025
Why does my Whirlpool ACD052MM keep tripping the house circuit?
- M
  Michael JohnsonAug 26, 2025
  If your Whirlpool Air Conditioner is tripping the house circuit, consider these potential causes: * Incorrect fuse or breaker: Verify that the fuse or breaker is the proper type and size. Also, check the amp draw. * Failed component or incorrect wiring: Inspect the wiring and connections, and check the operation of all components.
M
Molly HaleyAug 27, 2025
How to reduce noise from my Whirlpool Air Conditioner?
- C
  Christopher HornAug 28, 2025
  If your Whirlpool Air Conditioner is operating noisily, consider these potential causes: * Loose parts: Check fan blades, cabinet, washers, tubing contact or vibration, or loose screws. * Mounting area not firm: Add a support kit or improve the installation. * Compressor issues: The compressor could be overloaded, have internal issues, inadequate lubrication, or be affected by improper voltage. Remove any airflow blockage. * Fan motor: Check for loose or rubbing fan blades, a bad bearing, or an unbalanced fan. * Compressor mounting nuts loose: Tighten the compressor nuts slightly to reduce vibration transmission.
B
Brad MurphyAug 30, 2025
Why does my Whirlpool ACD052MM Air Conditioner's compressor keep stopping and starting?
- E
  Emily ThompsonAug 30, 2025
  If your Whirlpool Air Conditioner's compressor stops and starts frequently with a short running time, check these: * Incorrect voltage: Ensure the unit is receiving the correct voltage. * Temperature control setting: Make sure the temperature control isn't set too warm. * Failed thermistor or thermostat: Test the thermistor by placing it in ice water and checking its resistance. * Failed compressor, controls, or wiring: Inspect the compressor windings, all wiring, overload, and capacitor for shorts. * Fan motor issues or blocked condenser airflow: Check for the correct motor, blower wheel, or fan blade. Look for low voltage, binding, and clean the condenser.
K
Kathryn WeaverSep 2, 2025
Why is the evaporator frosting up on my Whirlpool Air Conditioner?
- M
  Mike ThompsonSep 2, 2025
  If the evaporator is frosting up on your Whirlpool Air Conditioner, consider these potential causes: * Low outside air temperature: Operating the unit below 65°F is not considered normal. Adjust the controls to a warmer setting. * Thermistor failure: Test the thermistor by placing it in ice water and checking its resistance. * Improper airflow: Clean or replace the air filter. Check for obstructed or restricted air passage, a dirty evaporator, and a loose blower wheel, or missing seals. * Fan motor slow: Check for binding of the fan blade, blower wheel, or motor bearings. Use low fan speed.
P
Phillip WillisSep 5, 2025
What causes the fan motor to run but the compressor not to run on my Whirlpool Air Conditioner?
- S
  Shawn BrooksSep 5, 2025
  If the fan motor runs but the compressor doesn't on your Whirlpool Air Conditioner, it could be due to: * Incorrect power supply voltage: Verify that the unit is receiving the proper voltage. * Failed component or incorrect wiring: Check all wiring connections, overload, compressor, capacitor, selector switch, or control.
C
Christopher WoodsSep 7, 2025
What to do if the compressor runs but the fan motor doesn't on my Whirlpool Air Conditioner?
- A
  Antonio BrownSep 8, 2025
  If the compressor runs but the fan motor does not run on your Whirlpool Air Conditioner, check the following: * Blower wheel or fan blade binding: Ensure proper clearance. * Incorrect wiring: Inspect all wiring. * Motor issues: Check for open or shorted motor windings, an open selector switch, or control problems.
D
Desiree HornSep 12, 2025
Why is my Whirlpool ACD052MM dripping moisture into the room?
- M
  Maurice BishopSep 12, 2025
  If your Whirlpool Air Conditioner is dripping moisture into the room, here are some possible reasons: * Extreme humidity: This can cause sweating formations. Improve all possible seals. * Inadequate seal: Check and improve all sealed areas. * Improper level: Ensure the unit is level from side to side and has a slight rear slope. * Broken or missing styrofoam shield: Replace the styrofoam shield under the evaporator coil.
