48
EN
TROUBLESHOOTING GUIDE
IF THE POWER CORD NEEDS REPLACING it should
be replaced by the original
power cord, which is avail-
able via our service organ-
isation. The power cord
should only be replaced by
a trained service technician.
SERVICE ONLY TO BE CARRIED OUT
BY A TRAINED SERVICE TECHNICIAN.
It is hazardous for anyone
other than trained staff to
carry out any maintenance
or repair operation which in-
volves the removal of any
cover which provides protection against
exposure to microwave energy.
DO NOT REMOVE ANY COVERS.
IF THE OVEN DOES NOT WORK, do not make a service
call until you have made the following checks:
The turntable and turntable support is in
place.
The door is properly closed.
Check the fuses and make sure that there is
power available.
Check that the oven has ample ventilation.
Wait for 10 minutes, then try to operate the
oven once more.
Open and then close the door before you
try again.
Disconnect the oven from the power sup-
ply. Wait for 10 minutes before reconnect-
ing and trying again.
THIS IS TO AVOID making unnecessary calls for
which you will be charged.
When calling Service, please give the serial
number and type number of the oven (see Ser-
vice label). Consult your warranty booklet for
further advice.
DATA FOR TESTING HEATING PERFORMANCE
IN ACCORDANCE WITH IEC 60705.
THE INTERNATIONAL ELECTROTECHNICAL COMMISSION has developed a standard for comparative testing of the
heating performance of different microwave ovens. We recommend the following for this oven:
TEST AMOUNT APPROX. TIME POWER LEVEL CONTAINER
12.3.1 1000 G 12 - 13 MIN 650 W PYREX 3.227
12. 3. 2 475
G 5 ½ MIN 650 W PYREX 3.827
12.3.3 900
G 13 - 14 MIN 750 W PYREX 3.838
13.3 500
G 10 MIN 160 W
TECHNICAL SPECIFICATIONS
SUPPLY VOLTAGE 230 V/50 HZ
RATED POWER INPUT 2300 W
F
USE 10 A
MW
OUTPUT POWER 1000 W
G
RILL 800 W
O
UTER DIMENSIONS (HXWXD) 385 X 595 X 468
I
NNER DIMENSIONS (HXWXD) 200 X 405 X 380
