Whirlpool AWM 8143 - Drain Pump and Program Timer

SERVICE
Whirlpool Europe AWM 8143 01.04.2004 / Page 3
Customer Service 8570 814 53900 Doc. No: 4812 722 22466
Technical data
Drain pump (synchronous)
Nominal Voltage 220/240 V
Nominal current 0.3 A
Nominal power 34 W
Frequency 50 Hz
Resistor (coil) 155 Ω± 7%
Motor protection yes 170 ˚C
Capacity (1.25m height) 15 ± 2 l/min
Program timer
Type SC1 - 3322
Timer basic 4619 710 67642
Timer programmed 4619 751 52151
Nominal voltage 230 V
Frequency 50 Hz
Detergent dispenser 3
Spin speed 1400 rpm
Cold fill yes
Hot fill yes
Connector
OA4.1 - OA4.2 5. Option
OA4.3 - OA4.4 6. Option
OB4.1 - OB4.2 3. Option
OB4.3 - OB4.4 4. Option
OC4.1 - OC4.2 1. Option
OC4.3 - OC4.4 2. Option
SLT3.1 - SLT3.3 Temp.selector
SLS4.1 - SLS4.4 Spin speed selector
VCF3.1 - VCF3.3 Valve (cold water)
VHF3.1 - VHF3.3 Valve (hot water)
Pi5.1 = negative supply
Pi5.2 = data
Pi5.3 = clock
Pi5.4 = positive supply
Pi 5.5 = negative supply
PL3.1 - PL3.3 Pilot lamp
Connector
M7.1 - M7.7 Motor
DP2.1 - DP2.2 Pump
AQS2.1 - AQS2.2 Aquastopswitch
SET2.1 - SET2.2 NTC
DSS3.1 - DSS3.3 Door switch
PR2.1 - PR2.2 Pressostat
Single connector
HE2.1 - HE2.2 Heating element
PS2.1 - PS2.2 Pressostat
SM3.2 - SM3.3 mains switch
(3 fold connector)
Program 32 positions
Ambient temperature up to 70 ˚C
Storage temperature up to 85 ˚C
Wash speed 54 rpm
Ramp speed 95 rpm
Spin speed 1400 rpm
Spin reduction - 5 steps
1360 rpm
880 rpm
440 rpm
95 rpm
0 rpm
Output
Motor M7.6 - DSS3.2 >40 V
Aquastop AQ2.2 - DSS3.2 230 V
in pump step AQ2.1 - DSS3.2 230 V
NTC not measurable
Pump DP2.1 - DP2.2 230 V
Doorlock DSS3.1 - DSS3.3 230 V
Pressostat E4 - E2 230 V
- empty PR2.1 - E2 230 V
- full PR2.2 - E2 230 V
Valve (Rast 2.5) V2.1 - V2.2 >170 V
Options not measurable
Display module Pi5.1 - Pi5.4 5 V
Pi5.4 - Pi5.5 12 V
Motor
Type Siemens
BSH 1BA 6760-0 WA
Belt ratio i = 1:12.36
Resistance contacts
1 - 2 13.07 Ω ± 7%
Rotor direct 1.80 Ω ± 7%
5 - 6 1.75 Ω ± 7%
5 - 7 0.82 Ω ± 7%
Cotton-/
cooured
Easy
care
Delicate Wool Silk
Pre wash 02 - 06 03 - 06 04 - 06 - -
Main wash 07 - 21 12 - 21 14 - 21 17 - 21 18 - 21
Rinse 22 - 28 22 - 28 22 - 28 22 - 28 22 - 28
Spin 29 - 31 29 - 31 29 - 31 29 - 31 29 - 31
Stop 32 32 32 32 32
