【 】Names of the device and functions
1. Main Body
2.Remote LCD Display Screen
Battery exchange
Signal delivering
Time display
LCD function display area
Air inlet cover
Air outlet joint
Automatic louver
Screw cover
Pre-filter
Signal receiver
Front panel
Frequency button
Main body
Ionizer
Oscillation
(Super/Hi/Lo)
-04-
Dry (乾燥功能)
Heat (暖氣功能)
Quick Heat (速暖功能)
Fan (涼風功能)
Vent (換氣功能)
Vent 24Hr (24小時換氣功能)
Heat
Fan
Vent 24 Hr
2 Hr
8 Hr
Lo
Air Volume
Time setting display
(6 sense /2/4/8 Hours)
th
