French-Door Boom Mount Refrigerator
FORWARD
This Whirlpool Service Manual (Part No. W11366204), provides the In-Home Service Professional with service
informaon for the “French-Door Boom Mount Refrigerator.”
The Wiring Diagram used in this Service Manual is typical and should be used for training purposes only. Always
use the Wiring Diagram supplied with the product tech sheet when servicing the refrigerator.
For specic operang and installaon informaon on the model being serviced, refer to the “Use and Care
Guide” or “Installaon Instrucons” provided with the refrigerator.
GOALS AND OBJECTIVES
The goal of this Service Manual is to provide informaon that will enable the In-Home Service Professional to
properly diagnose malfuncons and repair the “French-Door Boom Mount Refrigerator.”
The objecves of this Service Manual are to:
• Understand and follow proper safety precauons.
• Successfully troubleshoot and diagnose malfuncons.
• Successfully perform necessary repairs.
WHIRLPOOL CORPORATION assumes no responsibility for any repairs made on our
products by anyone other than authorized In-Home Service Professionals.
©2019 Whirlpool Corporaon. Benton Harbor, MI 49022
