Whirlpool LCE4332PQ User Manual

1-4
SPECIFICATIONS
WASHING SYSTEM
Washing System Agitator
Agitator Type Single Action
Basket Spinning (High) 750 rpm
Dispenser Yes - 1 drawer
Strokes Per Minute
Heavy Duty (Max) 64 spm
Normal (Max) 68 spm
Quick Wash (Max) 64 spm
Delicate (Max) 35 spm
ELECTRICAL
Nominal Voltage 120 VAC
Voltage Range 100 - 130 VAC
Frequency 60 Hz
Current (Rated) 5 amps
Motor
Power 1/4 HP
Rotation 1625 rpm
Current (Rated) 3 amps
Type PSC - Bi-directional
Drain Pump
Power 36 Watts
Current 0.8 amps
Flow 24 liters/minute
Capacitance
45 µF
Circuit Breaker 15 amps (recommended)
HYDRAULIC
Max. Water Consumption (All Cycles)
High 33 gal./124 l
Medium 17 gal./64 l
Water Pressure
Maximum 690 kPa/100 psi
Minimum 34.5 kPa/5 psi
Water Level
High Just below balance ring
Medium 5 rows below balance ring
DIMENSIONS
Net Weight 86.4 lbs. (39.2 kg)
Height 38.2 in. (970 mm)
Width 22.2 in. (565 mm)
Depth 24.6 in. (625 mm)
Height W/Lid Open 51.1 in. (1300 mm)
Weight W/Package 94.8 lbs. (43 kg)
Height W/Package 41.7 in. (1060 mm)
Depth W/Package 26.6 in. (675 mm)
Width W/Package 25 in. (635 mm)
WASHER MODEL LCE4332PQ0

Whirlpool LCE4332PQ Specifications

General

Brand	Whirlpool
Model	LCE4332PQ
Type	Top Load Washer
Color	White
Energy Star Certified	No
Agitator	Yes
Delay Wash	No
Quick Wash	Yes
Deep Fill Option	Yes
Spin Speed	700 RPM
Width	27 in
Depth	27 in
Weight	140 lbs
Water Level Selection	Automatic
Height	43 inch
