PARTS AND FEATURES
The parts and features of your dryer are illustrated on this page. Become familiar with all parts and
features before using your dryer. Page references are included next to some features. Refer to
those pages for more information about the features.
CONTROL PANEL
Towels / Work Clothes
F
I
N
I
S
H
G
U
A
R
D
Start button/Cycle
signal selector
(p. 8, 9)
Lint screen
(p. 13)
Cycle control
knob
(pp. 8-10)
Model and
serial number
label
(p. 2)
Dryer drum
(p. 14)
Wide-opening
door
Exhaust grill
Fabric/Temp. selector
(pp. 8-10)
FINISH GUARD
®
selector
(p. 8)
Other features not shown:
Drying rack (available as an option)
(p. 12)
Drum light
(p. 15)
