LOWER OVEN PARTS
2
8185829
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 Literature Parts
LIT4450409 Installation
Instructions
LIT4450568 Use & Care Guide
(Oven)
LIT4451887 Tech Sheet
LIT3191638 Safer Cooking Tips
2 Trim, Side
4450850 RH Black
4450851 RH White
4452122 RH Biscuit
4450853 LH Black
4450854 LH White
4452123 LH Biscuit
Screw
4449747 Black Model
4449041 White
4 4448520 Bumper, Door
6 Receiver, Hinge
4455605 Left Hand
4455606 Right Hand
7 4455284 Top Chassis
4449809 Screw
9 4452159 Tube, Vent
3196176 Screw
10 4451664 Fan & Bracket Assy.
4449809 Screw
11 4452368 Oven Light Assy
4449809 Screw
12 4452166 Bulb, Light
13 4452165 Lens, Light
14 4455610 Frame, Front
4449040 Screw
4450118 Nut
15 4450491 Gasket, Door
19 4451476 Support, Insulation
25 4455641 Side, Chassis
(R.H. & L.H.)
4449809 Screw
26 4452232 Back, Chassis
4449809 Screw
27 Liner, Oven
(Not serviceable)
29 4455636 Sensor
4449154 Screw
37 4451354 Fuse−Thermal
4449809 Screw
43 4450525 Base, Chassis
4449154 Screw
49 4448933 Retainer, Gasket
4449154 Screw
50 4451747 Cover, Back
4449809 Screw
51 Trim, Bottom
4448473 Black Model
4448474 White Model
8300528 Biscuit Model
4159465 Screw
53 4449845 Support, Bracket
4449809 Screw
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449314 Insulation, Wrap
4450363 Insulation, Back
For Models:RBD245PDB12, RBD245PDQ12, RBD245PDT12,RBD245PDS12
(Black) (Designer White) (Biscuit) (Stainless Steel)
