2. Install the dryer with stacking kit on the top of the front load washing
machine (Fig.3). Drill two holes on both sides of washer with 2.9mm
diameter drill. Detailed drill position as shown on the stacking kit. Make
sure the included screws are used. Fix the stacking kit on the top
cover of washing machine, as shown on Fig.4.
8
Dryer
Washer
Stacking kit
Fig.3
Fig.4
INSTALLATION INSTRUCTIONS
