Whirlpool 27' User Manual (English)

Questions and Answers:

J
Jessica ChanJul 27, 2025
Why my Whirlpool 27' won't start?
- M
  Marisa BradfordJul 27, 2025
  If your Whirlpool Dryer won't start, there could be several reasons. It might be due to no power to the unit, so check the voltage supply. The door switch may not be making contact; in this case, check the door switch wiring and continuity. Also, the thermal fuse might be open, so check the fuse continuity. A broken belt or belt switch could also be the cause; inspect for a broken belt or check the belt switch for continuity. Finally, the timer motor push-to-start relay could be faulty; check the timer contacts for continuity. You can also check voltage to motor, contacts 4 & 5, (120VAC); check motor windings for continuity, (2-4 ohms); check PTS contacts R1 - R2, while pushing start switch; check PTS relay coil R2 - CT1 for continuity.
L
Laura NealAug 3, 2025
Why is my Whirlpool Dryer not heating?
- S
  Shannon HarperAug 3, 2025
  If your Whirlpool Dryer is not heating, it could be due to several reasons. First, check for proper voltage supply (240VAC for electric dryers). The heater element, gas burner thermostat, thermal cut-off, hi-limit thermostat, or motor centrifugal switch could be faulty; check the heater continuity (8-12 ohms). Also, check for voltage (120VAC) to the burner assembly; check ignitor continuity; check for gas supply; check flame switch continuity (0 ohms when cold); check gas valves for continuity; check thermostat for continuity and manually close centrifugal switch contacts, check for continuity, (1M-2M ohms).
G
Gary BennettAug 11, 2025
Why won't the auto cycle timer advance on my Whirlpool Dryer?
- M
  Melissa MillerAug 11, 2025
  If the auto cycle timer won’t advance on your Whirlpool Dryer, it could be due to the timer electronic control or dryness sensor. Check timer motor continuity (4000-6000 ohms).
L
Lisa BrownAug 18, 2025
What causes a Whirlpool 27' to get too hot?
- A
  Amanda JonesAug 18, 2025
  If your Whirlpool Dryer's temperature is too hot, it could be due to a thermostat heater being open. Check the heater for continuity (3200-4000 ohms). Also, check selector and wiring for continuity.

Whirlpool 27' Specifications

General

Brand	Whirlpool
Type	Electric or Gas
Wrinkle Control Option	Yes
Width	27 inches
Color	White
Energy Star Certified	Varies by model

Summary

INTRODUCTION

GOALS AND OBJECTIVES

Outlines the purpose and learning outcomes of the job aid for service technicians.

SECTION ONE GENERAL INFORMATION

Electrical Requirements and Grounding

Details power supply specifications and grounding methods for gas and electric dryers.

Recommended Grounding Method

Explains the proper procedure for grounding the appliance to prevent electrical hazards.

Electric Dryer Electrical Connection

Specifies the required voltage, amperage, circuit type, and connection method for electric dryers.

Grounding Instructions

Provides detailed steps for connecting the appliance to a grounded electrical system.

Exhaust Requirements for Gas and Electric Dryers

Covers proper ducting, installation, and safety for dryer exhaust systems to prevent fire hazards.

Gas Requirements for Gas Dryers

Details gas supply line connections, pressure, shut-off valves, and ventilation requirements.

Recessed and Closet Installation

Provides spacing and ventilation guidelines for installing dryers in confined areas like closets.

SECTION TWO THEORY OF OPERATION

Console and Timer Control Overview

Describes the dryer's control panel, including the electronic control and timer functions.

Electronic Dry-Miser Cycle

Explains the automatic drying cycle based on moisture sensing and cool-down periods.

Timed Dry Cycle Operation

Details the operation of the timed drying cycle, including heated drying and cool-down.

Fluff Air Cycle and Control Pad Functions

Covers the unheated fluff air cycle and the functions of the clean touch control pad buttons.

Electronic Control System Operation

Explains the C version electronic control system, moisture sensor, and push-to-start knob.

Heated Air Circulation

Illustrates how air is drawn, heated, circulated in the drum, and exhausted from the dryer.

Side and Bottom Exhaust Venting Kits

Information on optional kits for venting the dryer through the side or bottom.

SECTION THREE COMPONENT ACCESS

Console Control Repairs and Removal

Provides instructions for accessing and removing the dryer's console and its components.

Console Component Removal

Step-by-step guides for removing the timer, switch assembly, buzzer, and control board.

Dryer Top Removal

Detailed steps for removing the top panel of the dryer.

Component Replacement: Lamp, Switch, Panel

Instructions for replacing the drum lamp, door switch, and removing the toe panel.

Blower Wheel and Housing Removal

Steps for removing and replacing the blower wheel and its housing.

Motor, Thermostat, Fuse Replacement

Procedures for replacing the drive motor, operating thermostat, bias heater, and thermal fuse.

Heating Element and Burner Assembly Replacement

Instructions for replacing the electric heating element or the gas burner assembly.

High Limit Thermostat and Heat Duct Replacement

Guides for replacing the high limit thermostat, thermal cutoff, and heat duct assembly.

Dryer Door and Front Panel Removal

Steps for removing the dryer door, its springs, and the front panel.

Drum Belt and Support Roller Replacement

Procedures for removing the drum belt and replacing front support rollers and shafts.

Grille Assembly Removal

Steps for removing the front grille assembly.

Rear Bulkhead Assembly Removal and Reattachment

Guides for removing and reinstalling the rear bulkhead assembly.

SECTION FOUR TROUBLESHOOTING AND DIAGNOSIS

Troubleshooting Guide

A table listing common dryer problems, their possible causes, and solutions.

Electronic Control Component Testing

Tests to diagnose issues with the electronic control board, moisture sensor, and timer switches.

SECTION FIVE TECH TIPS

Wiring Diagrams

Presents the wiring schematic for the electric dryer, detailing component connections.

Gas Dryer Wiring Diagram

Provides the electrical schematic for the gas dryer, illustrating component interconnections.

Timer Schedule and Strip Circuits

Explains timer contact states and provides diagrams of specific electrical circuits.

Key Circuit Operations

Details the operation of temperature control, heater, burner, and push-to-start circuits.

Additional Circuit Operations

Explains the operation of buzzer, drum lamp, and timer motor circuits.

MODEL/SERIAL NUMBER INFORMATION

Plate Location and Designations

Describes the location of the model/serial number plate and the meaning of its designations.
