Section Two - Deactivating ADCWFI Control Routine
1) Locate resistor number 15 (R15) on top side of circuit board (gure. 2)
2) Using wire cutters clip both legs (wire) of the resistor as close to the board
surface as possible.
3) With resistor removed, no leg (wire) of the resistor should be able to make
contact with any other component. The legs(wire) should be removed as
close to the circuit board as possible (gure 2A)
4) The ADC routine is now deactivated.
5) Reinstall all components and wiring harnesses
6) Replace all parts and panels
7) Plug in refrigerator or reconnect power.
Figure 2
Figure 2A
ADCWFI
ADCWFI
R15 Removed
Location of R15
