F
F
F
A
B
C
D min= 0
E min=50
F
G
H
Keep enough space of door open.
Keep at least 50mm gap at two sides and back.
Take left hinge cover from accesary bag and install it with top hinge. Then install
hole cover at right side.
Detach the frige and the freezer door gaskets and then attach them after rotating.
Space Requirement
Levelling the unit
To do this adjust the two levelling feet at front of the unit.
lf the unit is not level, the doors and magnetic seal
alignments will not be covered properly.
13 14
INSTALLATION
INSTALLATION
