Whirlpool WVW53UC0LS - Wiring Diagram

11
WIRING DIAGRAM
L
REMOTE SWITCH
FOR ADA COMPLIANCE ADD
THESE ELEMENTS DURING THE
INSTALLATION.
SEL0169984
Mechanical Push Buttons
(4 button 3 Speeds)
LED
LED
M
BR
YL YL
3
2
1
4
5
6
7
8
9
RD
BR
WH
BU
GY
BK
WH BU BK
12.5uF
WH
BK
BK
YL - GN
BK
BU
WH
BR
YL
BR
WH WH
YL
WH
PUSH BUTTON SWITCH OPERATION
FUNCTION
OFF
LAMPS
LOW SPEED
MED SPEED
HIGH SPEED
POSITION
NO CONNECTION
BROWN / YELLOW
(L-1)
BROWN / WHITE
(L-2)
BROWN / BLUE
(L-3)
BROWN / BLACK
(L-4)
MOTOR SPECIFICATIONS
POWER SUPPLY
FREQUENCY
POWER ABSORTION
120 VAC
60 Hz
240 W
MOTOR RESISTANCE (Ω)
S40
YL
WH
YL - GN
BLUE / BLACK
BLUE / GREY
BLUE / RED
BLUE / WHITE
17.7
27.1
34.6
41,2
YL - GN
L
