Page 8 | 1-800-343-9463
CWSK.PS4000.B
082015
Secure both wires into the H1 lever connector.
Secure the red female disconnect labeled 8
onto the #8 terminal on the contactor.
Remove the backing of the double sided tape
from the bottom of the Cold Weather Start Kit
electrical box.
Center the Cold Weather Start Kit box on the top of
the condenser coil. (BE SURE TO PUSH THE PLASTIC
STRAP ON THE BOX ALL THE WAY AGAINST
THE COIL COVER.)
15
16
17
18
