WhisperKool Platinum Split 4000 User Manual

www.whisperkool.com | Page 7
Zip tie the black wires with the closed end terminal,
as shown.
Remove the yellow female disconnect from the #8
terminal on the contractor.
Cut the yellow female disconnect o of the black
and blue wires.
Strip the blue and black wires as shown.
11
12
13
14
