Page 6 | 1-800-343-9463
CWSK.PS4000.B
082015
Separate, twist, and trim the copper strands of each
wire to a length of 3/8”.
Loosen the 2 Phillips screws on the cord squeeze.
Secure all 4 neutral wires into the lever connector
labeled N1.
NOTE: To secure a wire into the lever connector.
Pull a lever to the open position, insert wire,
and close lever.
Zip tie ground wires as shown.
7
8
9
10
