Page 22 | 1-800-343-9463
CWSK.PS4000.B
082015
Wall Mounted Units
Pull front panel away from the unit to remove it. Set
panel aside.
Ducted Units
Using a Phillips Head Screw driver loosen the 4 screws
on the ducting panel, make sure screw comes all the
way out of the housing of the unit. (Note: The screws
do not come out of the panel.) Pull ducting panel away
from the unit to remove it.
Remove the panel.
Remove the thumbscrew by rotating it counter
clockwise. (Set thumbscrew aside for later use.)
6
7
8
9
To Next Page
