www.whisperkool.com | Page 23
Pull electrical panel out and let hang as shown.
Remove the backing from the double sided tape on
the bottom and side edges of the transformer.
Place ange of the transformer between the control box
and the ange of the electrical panel, place the other
ange underneath the grommet. Press transformer
rmly in place.
Locate one of the white wires coming out of the push
connector. Cut one white wire and strip both ends to a
length of 3/8”.
10
11
12
13
