www.whisperkool.com | Page 25
Secure the other t-stat wire and the yellow wire
coming from the 24v side of the transformer into a
lever connector.
Zip tie wires in locations shown.
Slide the electrical panel back into place and re-install
the thumb screw.
Wall Mounted Units
Push front panel back on the unit, and tighten the 2
Phillips head screws on the front panel to the unit.
18
19
20
21
