Figure 6-12
6
Maintaining
Your Lawn
Tractor
WARNING
Be sure to shut
the engine off,
remove ignition key,
disconnect the spark
plug wire(s) and
ground against the
engine to prevent
unintended starting
before removing the
belt.
Avoid the possibility
of a pinching injury.
Do not place your
fingers on the idler
spring or between the
belt and a pulley while
removing the belt.
Changing the Lower Deck Belt (46” Decks)
NOTE: Several components must be removed in order to change the tractor’s lower deck belt. See an authorized
Service Dealer to have your lower drive belt replaced or phone Customer Support as instructed on page 2 for informa-
tion on ordering a Service Manual.
Changing the Transmission Drive Belt
NOTE: Several components must be removed and special tools (i.e. air/impact wrench) in order to change the
tractor’s drive belt. See an authorized ervice Dealer to have your drive belt replaced or phone Customer Support as
instructed on page 2 for information on ordering a Service Manual.
Figure 6-13
Deck Idler Pulleys
Engine Pulley
Belt Cover
46-Inch Deck
To Next Page
