SETTING
THE
NEEDLE
See
Fig,
3.
Raise
the
needle
bar
A
to
its
highest
point,
turn
ing
wheel
toward
you
by
hand.
Then
loosen
the
needle
clamp
screw
B
and
the
needle
clamp
C
will
open.
Place
needle
flat
side
to
back
in
the
needle
clamp
and
push
it
upward
as
far
as
it
will
go
into
the
needle
clamp
hole,
fastening
the
needle
clamp
securely
with
a
screw
driver.
WINDING
THE
BOBBIN•
Disengage
the
hand
wheel
Fig.
4
from
the
stitching
mechanism
by
turning
the
clutch
toward
you
or
counterclock
wise.
Place
a
spool
of
thread
on
one
of
the
spool
pins,
lead
thread
under
the
handle
and
through
the
upper
thread
guide
on
the
arm,
and
down
through
the
tension
disc
11,
Fig.
5
at
the
base
of
the
machine.
Run
end
of
thread
through
a
hole
in
the
bobbin
edge
and
place
bobbin
on spindle
B
of
winder
4,
fitting
the
notch
on
bobbin
over
small
pin
on
spindle.
Push
Fig.
3
Fig.
4
